AC Isolation Switch LYAS5 Series,
The EAS Series AC isolation switches are suitable for switching on,
and off AC circuit systems, such as in PV systems and air conditioning systems.
This weatherproof disconnector is particularly suited for outdoor installation and can achieve IP66 protection level.
The base mounted mechanism provides more convenient termination and wiring room.
According to EN60947-3 AS/NZS 60947-3.
Features
Switching ON &OFF on-load
4pcs screws with protective caps for high strength locking
IP66& UV resistance and flame-retardant material
Dual 25mm threaded conduit entries on top and bottom
Pad-lockable handle
5 years warranty, productinsurance, and recall insurance available
| Type designation | LYAS5EL/20 | LYAS5EL/35 | LYAS5EL/63 |
| Ambient temperature | -5°℃ ~+40°C | ||
| Interrupting medium | Air | ||
| Utilization category | AC-22A | ||
| Rated operational voltage (Ue) /current (Ie) | N: AC250V(1P), AC440V(2P/3P/4P) NS:AC250V(1P/2P) |
||
| 20A | 35A | 63A | |
| Rated frequency | 50/60Hz | ||
| Rated Insulation voltage (Ui) | 500 V | ||
| Conventional free air thermal current (Ith) | / | / | / |
| Conventional enclosed thermal current (lthe) | / | / | / |
| Rated short-time withstand current (Icw) | 20A | 35A | 63A |
| Rated short-time making capacity (Icm) | 0.76kA, 1s | ||
| Rated conditional short-circuit current (Icn) | 1.5kA | ||
| Short circuit protective device | // | ||
| Rated lmpulse withstand voltage (Uimp) | 4 kV | ||
| Overvoltage category | Ⅱ | ||
| IP code | IP66 | ||
| Pollution degree | 3 | ||
| Suitability for isolation | yes | ||
