CBS220-24T-4G Cisco CBS220-24T-4G Switch 24xGE+4xSFP/rack-mount/smart switch

CBS220-24T-4G Cisco CBS220-24T-4G Switch 24xGE+4xSFP/rack-mount/smart switch

Add to wishlist
Category: Terminals & Bars
Share: Facebook Twitter Tumblr Linkedin Whatsapp

You may also like

  • Danfoss Pressure switch, RT200 017-140066 Regulation range [bar] Pe: 0.2 - 6, Differential [bar]: 0.25 - 1.2, Contact function: SPDT, Reset function: Auto, Pressure connection type: G, Pressure connection size: 3/8, Pressure Male/Female: Male, Enclosure rating IP: IP66, Max. Working Pressure [bar]: 22

    Danfoss Pressure switch, RT200 017-140066 Regulation range [bar] Pe: 0.2 - 6, Differential [bar]: 0.25 - 1.2, Contact function: SPDT, Reset function: Auto, Pressure connection type: G, Pressure connection size: 3/8, Pressure Male/Female: Male, Enclosure rating IP: IP66, Max. Working Pressure [bar]: 22

  • SMC NCMK Non-rotating Single Acting Spring Return

    SMC NCMK Non-rotating Single Acting Spring Return

  • CHINT NM1 Moulded Case Circuit Breaker

    CHINT NM1 Moulded Case Circuit Breaker

  • MWI808 800A 4P ACB Cutler Hammer GHAS

    MWI808 800A 4P ACB Cutler Hammer GHAS

  • 1234231 / E-WM (EX23)R Phoenix Contact  Marking foil, Roll, white, unmarked, can be labeled with: THERMOMARK E.WIRE, cable diameter range

    1234231 / E-WM (EX23)R Phoenix Contact Marking foil, Roll, white, unmarked, can be labeled with: THERMOMARK E.WIRE, cable diameter range

  • Siemens 243-0019 Signal Selector Lowest/Highest Pneumatic

    Siemens 243-0019 Signal Selector Lowest/Highest Pneumatic

Description
Shipping & delivery

CBS220-24T-4G Cisco CBS220-24T-4G Switch 24xGE+4xSFP/rack-mount/smart switch,

Cisco CBS220-24T-4G Overview



The Cisco Business 220 Series are affordable smart switches with ease of use, security, and reliability for business-class networks. With intuitive dashboard, and customizable features, these switches deliver a solid business network within your budget parameters. When you need a business-class network and cost is top priority, Cisco Business 220 Series provides an excellent solution.

Quick Specs

Table 1 shows the Quick Specs.

Product Code CBS220-24T-4G
Forwarding performance 41.66 Mpps
Switching capacity 56 Gbps
Dimensions (WxDxH) 17.3 in x 8 in x 1.7 in
Ports 24 x 10/100/1000 + 4 x Gigabit SFP (uplink)
RAM 256 MB
Flash Memory 64 MB

Product Details

Easy configuration and deployment:

Cisco Business 220 Series switches are designed to be easy to deploy and use by small businesses and the partners that manage them.

Reliability and performance:

Cisco Business 220 Series switches have been tested to deliver the high availability and performance that users have come to expect from Cisco switches. The switches speed up file transfer times, keep vital business applications available, and help your employees respond more quickly to customers and each other. With enhanced QoS capabilities, the Cisco Business 220 Series also gives you the flexibility to manage and prioritize high-bandwidth traffic so you can easily integrate all the business communications and connectivity needs on a single converged infrastructure.

Network security:

The Cisco Business 220 Series switches provide high levels of security for smart switches and deliver more ways to safeguard your network.

Optimal energy efficiency:

Cisco Business 220 Series switches are designed with Energy Efficient Ethernet (IEEE 802.3az) and Energy Detect support.

Peace of mind and investment protection:

Cisco Business 220 Series switches offer the reliable performance, investment protection, and peace of mind you expect from a Cisco switch.

Supported Modules

Table 2 shows the supported SFP/SFP+ modules of Cisco Business 250 Series Switches.

SKU Media Speed Maximum distance
MGBSX1 Multimode fiber 1000 Mbps 500 m
MGBLH1 Single-mode fiber 1000 Mbps 40 km
MGBLX1 Single-mode fiber 1000 Mbps 10 km
MGBT1 UTP cat 5e 1000 Mbps 100 m
GLC-SX-MMD Multimode fiber 1000 Mbps 550 m
GLC-LH-SMD Single-mode fiber 1000 Mbps 10 km
GLC-BX-U Single-mode fiber 1000 Mbps 10 km
GLC-BX-D Single-mode fiber 1000 Mbps 10 km
GLC-TE UTP cat 5e 1000 Mbps 100 m
SFP-H10GB-CU1M Copper coax 10 Gig 1 m
SFP-10G-SR Multimode fiber 10 Gig 26 m – 400 m
SFP-10G-LR Single-mode fiber 10 Gig 10 km
SFP-10G-SR-S Multimode fiber 10 Gig 26 m – 400 m
SFP-10G-LR-S Single-mode fiber 10 Gig 10 km
