CHINT CB-60B Moulded Case Circuit Breaker (MCCB),
provides dependable overload and short-circuit protection for AC and DC circuits up to 415 V and 63 A.
furthermore it Build for precision and durability, it features a 6 kA breaking capacity,
in addition to B/C tripping curves, and thermomagnetic trip technology for stable performance.
moreover Compact and easy to install, the CB-60B is designed to ensure safe, efficient power distribution in residential, commercial,
and finally industrial systems, fully compliant with IEC/EN 60947-2 standards.
- Standard: IEC/EN 60947-2
- furthermore Certifications: CE, TÜV, REACH
- in addition to Rated Current (In): 1–63 A
- moreover Rated Operating Voltage (Ue): AC 230/400~240/415 V
- Rated Insulation Voltage (Ui): 500 V
- specifically Rated Impulse Withstand Voltage (Uimp): 6 kV
- Rated Frequency: 50/60 Hz
- consequently Breaking Capacity (Icn): 6,000 A
- Tripping Characteristics: Type B (3–5 In) / Type C (5–10 In)
- Trip Unit Type: Thermomagnetic
- subsequently Energy Limiting Class: 3
- Dielectric Strength (1 min): 2 kV
- Mechanical Life: 20,000 operations
- Electrical Life: 10,000 operations
- after Operating Temperature: −25 °C to +70 °C
- before Storage Temperature: −25 °C to +70 °C
- Altitude: ≤ 2,000 m
- Connection: Top or bottom feed
- Terminal Type: Cable / U-type busbar / Pin-type busbar
- Terminal Capacity: Up to 25 mm²
- Tightening Torque: 2.5 N·m
- Mounting: DIN rail (35 mm)
- Protection Degree: IP20
- Housing Material: Flame-retardant thermoplastic (UL 94 V-0)
- Accessories: Auxiliary contact, shunt trip, under-voltage release, alarm contact
- finally Applications: Power distribution panels, lighting, and motor control circuits
