CHINT DDSU666-110

CHINT DDSU666-110

Add to wishlist
Category:
Brand:
Share:

CHINT DDSU666-110,

-MID B+D Certified

-Multi Parameter measurement

-Modbus-RTU Communication

-1 Module Din Rail Mounted

Measurement:

-Compliance with EN 50470-1/-3 standard

-Connection type: 1P2W

-Accuracy:Direct: Class B/1.0

-Access Method:Direct connection



Voltage:

-Nominal voltage (Un): 220V…240V

-Operating range:0.8Un ~ 1.15Un

-Power consumption: ≤2W, 10VA



Current: Direct,0.25-5(80)A



LCD Display:

-8 characters of 7 segment display

-Digital size:2.1mm×4.5mm



Display Interface:LCD



Communications:

-RS485,Modbus-RTU

-Baud Rate:1200bps, 2400bps, 4800bps, 9600bps(default), 19200bps



Environmental:

-Operating Temperature : -25°C to +55 °C

-Storage Temperature: 40 °C to +70 °C

-Relative Humidity: ≤ 95%RH (non-condensing)

-Ingress Protection: IP20



Measured Values:

-Import/Export/Total kWh

-Instantaneous kW, Irms, Vrms, Frequency, Power factor



LED Indication: Pluse Output



Dimensions and Weight:

-Dimensions: 18mm×100mm×65.5mm

-Weight: 0.08 kg (Approx.)
