Danfoss 018F6857 Solenoid coil BG024DS Supply voltage [V] DC: 24 Multi pack 5702428026260
Electrical connection: Terminal box, Supply voltage [V] DC: 24, Enclosure rating IP: IP67
Product details
| Gross weight | 0.596 Kilogram |
| Net weight | 0.568 Kilogram |
| Volume | 0.57 Liter |
| EAN | 5702428026260 |
| Type | BG024DS |
| Product group | Solenoid valves |
| Product Name Description | Solenoid coil |
| Actuator size | 13.5 mm |
| Ambient temperature range [°C] [max] | 50 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [max] | 120 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| Approval | CE CMIM EAC LLC CDC TYSK |
| CE evaluated | Yes |
| China RoHS compliance | Out of scope |
| Coil connection | Connection Box |
| Coil design standard | VDE 0580 |
| Coil fastening | Clip-on |
| Coil type | I |
| Coil winding insulation class | Class H to IEC 85 |
| Colour | Blue |
| Compliance | EN 60730-1 |
| Contains batteries | No |
| Duty rating | Continuous |
| EEE category | 5 small equipment (any external dimension < 50 cm) |
| Electrical connection | Terminal box |
| Electrical connection size | Pg 13.5 |
| Electrical connector | Screwed cable entry |
| Enclosure rating IP | IP67 |
| EU RoHS compliance | Out of scope |
| In scope of WEEE | Yes |
| Packing format | Multi pack |
| Parts Program name | EV210B EV212B EV220B 15 – 50 EV220B 6 – 22 EV220B 65 – 100 EV222B EV224B EV250B |
| Power consumption [W] DC | 20 W |
| Product accessories | Solenoid coil accessories |
| Quantity per packing format | 24 pc |
| REACH Candidate List substances | No |
| Rel. Humidity [% RH] [max] | 100 % |
| Rel. Humidity [% RH] [min] | 0 % |
| SCIP dossier product name | Solenoid coils |
| Serviceable | No |
| Spare part number | 018F6857 |
| Supply voltage [V] DC | 24 V |
| Type designation | BG024DS |
