Danfoss 060L112166 Thermostat KP77 5702428014878
Temperature range [°C]: 20 – 60, Reset function: Auto, Contact function: SPDT, Sensor type: Remote bulb, Capillary tube length [mm]: 2000, Enclosure rating IP: IP30
Product details
| Gross weight | 0.448 Kilogram |
| Net weight | 0.366 Kilogram |
| Volume | 1.468 Liter |
| EAN | 5702428014878 |
| Type | KP77 |
| Product group | Switches and thermostats |
| Product Name Description | Thermostat |
| Amb. Temp. Note | 80 °C/176 °F for max 120 min |
| Ambient temperature range [°C] [max] | 65 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [max] | 150 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| Approval | BV CCC CE CMIM DNV EAC GL LLC CDC EURO-TYSK LR LVD RINA RMRS RoHS China c UL us UL873, CS C22.2 |
| Cap. tube length fraction [in] | 78 3/4 in |
| Capillary tube length [mm] | 2000 mm |
| CE evaluated | Yes |
| Charge type | Adsorption |
| China RoHS compliance | Yes |
| Contact function | SPDT |
| Contact rating | AC15=10 A, 400 V AC1=16 A, 400 V AC3=16 A, 400 V DC13=12 W, 220 V LR=112 A, 400 V |
| Contains batteries | No |
| Diff. @ Max. range setting [K] [max] | 10 K |
| Diff. @ Max. range setting [K] [min] | 3.5 K |
| Diff. @ Max. range setting[°C] [max] | 10 °C |
| Diff. @ Max. range setting[°C] [min] | 3.5 °C |
| Diff. @ Min. range setting [K] [max] | 10 K |
| Diff. @ Min. range setting [K] [min] | 3.5 K |
| Diff. @ Min. range setting[°C] [max] | 10 °C |
| Diff. @ Min. range setting[°C] [min] | 3.5 °C |
| Differential type | Adjustable |
| Electrical connection | Rubber cable gland |
| Electrical connection size | 6-14 mm |
| Electrical spec. standard | EN 60947-5 |
| EN 60947 electrical properties | Insulation: 400V Pollution degree: 3 Rated impulse voltage: 4 kV Short circuit prot, fuse: 16A |
