Danfoss 132F0018 Frequency Converterc VLT® Micro Drive FC-51 FC-051PK75T4E20H3XXCXXXSXXX
Frequency Converter
FC-051PK75T4E20H3XXCXXXSXXX
NB: Last time buy June 30, 2026
VLT® Micro Drive FC-51
(PK75) 0.75 KW / 1.0 HP, Three phase
380 – 480 VAC, (E20) IP20 / Chassis
(H3) RFI Class A1/B (C1)
No brake chopper
No Loc. Cont. Panel
Coated PCB, No Mains Option
M1-FRAME
Other options according to Model code
Model code:FC-051PK75T4E20H3XXCXXXSXXX
The VLT® Micro Drive is a general-purpose drive that can control AC motors up to 22.0 kW. It is a small drive with maximum strength and reliability. The VLT® Micro Drive is manufactured with respect for the environment, and it complies with the RoHS Directive.
Product details
| Gross weight | 1.383 Kilogram | ||
| Net weight | 1.083 Kilogram | ||
| Volume | 4.498 Liter | ||
| EAN | 5702427357556 |
| Product View (Switch) | GLBL | Global (Standard) | |
| Product Group | FC- | VLT® Micro Drive FC- | |
| Micro Drive Series | 051 | 51 | |
| Power Rating | PK75 | (PK75) 0.75 KW / 1.0 HP | |
| Phase | T | Three phase | |
| Mains Voltage | 4 | 380 – 480 VAC | |
| Enclosure | E20 | (E20) IP20 / Chassis | |
| RFI Filter | H3 | (H3) RFI Class A1/B (C1) | |
| Brake – Safe Stop | X | No brake chopper | |
| LCP | X | No Loc. Cont. Panel | |
| Coating PCB | C | Coated PCB | |
| Mains Option | X | No Mains Option | |
| Adaptation A | X | Standard Cable Entries | |
| Adaptation B | X | No adaptation | |
| Software Release | SXXX | Latest release std. SW. | |
| Frame Size | M1 | M1-FRAME | |
| Typecode Part 1 | FC-051PK75T4E20H3XXCXXXSXXX | ||
| Modelcode01 | FC-051PK75T4E20H3XXCXXXSXXX | ||
| Product Catalog | NO_VIEW | NO VIEW | |
| Calculated Gross Weight [kg] | 1.4 | ||
| Calculated Net Weight [kg] | 1.1 | ||
| ECCN EU | Y901 | Y901 | |
| ECCN US | 3A999.a | 3A999.a | |
| Vendor | ERR01 | Cannot Determine Vendor | |
| Recommended Factory | ERR01 | Cannot Determine Vendor | |
| Recommended Plant | ERR01 | ERR01 | |
| DrivePro category | EXCH | Exchange Unit |
