Eaton UPS 9SX2000,
Eaton 9SX online, extended runtime UPS, 2000 VA, 1800 W, 5-20P input,
Outputs: (6) 5-20R, (1) L5-20R, 13.6″Hx8.4″Wx16.2″D, 77.2 lb., network card optional.
General specifications
| Product Name |
Eaton 9SX UPS
|
| Catalog Number |
9SX2000
|
| UPC |
743172091253
|
| Product Length/Depth |
16.2 in
|
| Product Height |
13.6 in
|
| Product Width |
8.4 in
|
| Product Weight |
77.2 lb
|
| Warranty |
3 year limited
|
| Compliances |
FCC Compliant
CE Marked |
| Certifications |
cULus Listed
ICC-ES AC156 OSHPD Seismic certified |
| Global Catalog |
9SX2000
|
| Product Type |
UPS
|
Battery
| Battery management |
ABM technology (3-stage charging extends battery service life by 50% and provides advance warning for battery replacement)
|
| Battery replacement |
Hot-swappable internal batteries and extended battery modules (EBMs)
|
| Extended battery capability |
Yes
|
Electrical output
| Receptacle |
(6) 5-20R, (1) L5-20R
|
| Topology |
Online/Double-conversion
|
| Wattage |
1800 W
|
| VA rating |
2000 VA
|
| Output waveform |
True sine wave
|
| Voltage |
120V
|
| Output power factor |
0.9
|
| Output nominal voltage |
120V default (100/110/120/125V)
|
| Output frequency |
50/60 Hz
|
| Feed type |
1
|
Electrical input
| Input connection |
5-20P
|
| Input cord length |
8 ft
|
| Input nominal voltage |
120 Default (100/110/120/125V)
|
| Input frequency range |
60 Hz: 50–70 Hz, 50 Hz: 40–60 Hz
|
| Input power factor |
>.99
|
Communications
| Communication |
|
| Expansion slots |
|
| User interface |
5-button graphical user interface
|
| Potential free switch contact |
Yes
|
Environmental
| Altitude |
3000 m
|
| BTU Rating |
Online : 813 BTU/hr, Battery : 1103 BTU/hr, High efficiency : 342 BTU/hr
|
| Noise level |
<53 dB at 1 meter
|
| Relative humidity |
0-96% non-condensing
|
| Temperature range |
0° to 40°C (32° to 104°F)
|
Additional specifications
| Construction type |
Free standing model
|
| Efficiency at max. load |
89.4%
|
| Package contents |
|
| Internal bypass |
Yes
|
Warranty and support
| Standard factory warranty |
|
| Extended service plans |
|
