MDR-100-24 Power Supply – 100W 24V 4A – Miniature,
Features:
Universal AC input / Full range
Installed on DIN rail TS35 / 7.5 or 15
Protections: Short circuit / Overload / Over voltage
No load power consumption <1W
LED indicator for power on
DC OK relay contact
Cooling by free air convection
100% full load burn-in test
Built-in active PFC and over temp. protection
3 years warranty
General Specification:
AC input voltage range:85~264VAC; 120~370VDC
AC inrush current:Cold start, 30A at 115VAC, 60A at 230VAC
DC adjustment range:0~+20% rated output voltage
Overload protection:105%~150% constant current limiting, auto-recovery
Over voltage protection:125%~150% rated output voltage
Setup, rise, hold up time:3000ms, 50ms, 50ms
Withstand voltage:I/P-O/P:3kVAC, I/P-FG:1.5kVAC, 1minute
Working temperature:-10~+60°C
DC OK signal:Relay contact
Safety standards:UL508, TUV EN60950-1 approved
EMC standards EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61204-3, EN61000-6-2 heavy industry level
Connection:IP: 3 poles, O/P: 6 poles screw DIN terminal
Dimension (LxWxH) :55x90x100
Packing:30pcs / 13.6kg
