21.5-Inch Industrial Multi-Touch Panel PC J1900 Mount Touch HD IP65,
Specifications
|
Model
|
ITPC-B215-CP2
|
|
Color
|
Gray+Silver
|
|
Material
|
Aluminum alloy chassis+ steel plate
|
|
Size
|
21.5 inch TFT-LCD
|
|
Ratio
|
16 : 9
|
|
Resolution
|
1920 * 1080
|
|
Brightness
|
250 cd/m2
|
|
Touch Screen
|
Multi point capacitive touch screen, with a lifespan of over 50 million times
|
|
Processor
|
Intel Celeron J1900
|
|
4th/5th gen Intel Core i5/i7 (the specific model is subject to shipment)
|
|
|
Chipset
|
Intel Graphics
|
|
RAM
|
J1900: 1 DDR3L 1333/1600 Ram slot, Max. 8GB
|
|
4th/5th Gen i5/i7: 2 DDR3L 1333/1600 Ram slot, Max. 16GB
|
|
|
Storage
|
Support 1x M.2 slot
|
|
Display Chip
|
Intel Graphics
|
|
Expansion Slot
|
6th Gen processor, Support 1x Mini PCIE slot (WIFI/4G Optional）
|
|
8/10/11th Gen processor, Support 2xM.2 slot (support WiFi+4G)
|
|
|
I/O
|
1 Power Switch, 1 DC , 1 HD-M-I, 1 VGA, 2 USB 3.0, 2 USB 2.0,
|
|
2 Gigabit Ethernet ports, 1 Mic, 1 Line Out, 2 COM (COM1,2 RS232/485)
|
|
|
Speaker
|
Two 8-ohm 2-watt speaker(customize the wide voltage, the number of speakers is 1)
|
|
Input Voltage
|
DC 12V (Optional 9-36V)
|
|
Work Temp
|
0℃ ~ +50℃, surface air flow
|
|
Humidity
|
5% ~ 95% non-condensing state
|
|
Input Voltage
|
DC 12V (Optional 9-36V)
|
|
Dimension
|
518 * 310 * 54 mm
|
|
Weight
|
3.9kg
|
|
Application
|
Industrial Automation, Medical, Logistics &Transportation, Warehousing,E-Education etc,.
|
