Danfoss  Pressure switch, KP35 060-113366 Regulation range [bar] Pe: -0.2 – 7.5, Differential [bar]: 0.7 – 4, Reset function: Auto, Pressure connection type: G, Pressure connection size: 1/4, Enclosure rating IP: IP30, Max. Working Pressure [bar]: 17

Type
Setting range Pe Dierential Permissible oper‐
ating pressure Pe
Max. test pres‐
sure Pressure connec‐
tion Contact material Code no.
[bar] [bar] [bar] [bar]
KP 35
-0.2 – 7.5 0.7 – 4.0 17 22 G 1⁄4 A silver 060-113366
060-113391 (1)
-0.2 – 7.5 0.7 – 4.0 17 22 G 1⁄4 A gold-plated 060-504766
-0.2 – 7.5 0.7 – 4.0 17 22 G 1⁄4 A silver 060-538666 (2)
-0.2 – 7.5 0.7 – 4.0 17 22 G 1⁄4 A silver 060-450366 (3)
KP 36
2.0– 14.0 0.7 – 4.0 17 22 G 1⁄4 A silver 060-110866
060-110891
2.0– 14.0 0.7 – 4.0 17 22 G 1⁄4 A gold 060-113766
2.0 – 14.0 0.7 – 4.0 17 22 G 1⁄4 A silver 060-450166(3)
2.0– 14.0 0.7 – 4.0 17 22 G 1⁄4 A silver 060-538766(2)
4.0 – 12.0 0.5 – 1.6 17 22 G 1⁄4 A silver 060-122166
4.0 – 12.0 0.5 – 1.6 17 22 G 1⁄4 A gold 060-114466
