Technical Table:
| Graduation | Accuracy | Thread Size | Wire Type | Temperature Range (°C) | Inner Lead Form | Wiring Form |
|---|---|---|---|---|---|---|
| PT100 | T | M8×1.25 | Metal Mesh Shielded Inner Glass Fiber | 400 | Two-Wire | Y-Terminal |
| PT100 | A | M8×1.25 | Hi-Temp Teflon PTFE Wrapping | 350 | Two-Wire | Y-Terminal |
| PT1000 | B | 5/16×24T | Teflon PFA | 260 | Three-Wire | Pin Terminal |
| PT1000 | C | 5/16×24T | Silicon Rubber | 180 | Four-Wire | Tail Half Stripping |
| PT1000 | – | 5/16×24T | Polyethylene PVC | 105 | – | – |
Text:
The product includes two graduations: PT100 and PT1000. The PT100 models offer accuracy classes T and A, with a thread size of M8×1.25, and are compatible with metal mesh shielded inner glass fiber (400°C) or Hi-Temp Teflon PTFE wrapping (350°C). Both PT100 variants use a two-wire inner lead form and Y-terminal wiring. The PT1000 models come in accuracy classes B and C, with a thread size of 5/16×24T, and support wire types like Teflon PFA (260°C), silicon rubber (180°C), and polyethylene PVC (105°C). The PT1000 models feature three-wire or four-wire inner lead forms and wiring forms such as pin terminal or tail half stripping.
