Compact Distribution Terminal Block
| Category | Specifications |
|---|---|
| Certifications | CB/CE/UKCA/RoHS |
| Dimensions | 50×130×50mm |
| Materials | • Screw: Zinc-Coated Steel • Conductor: Brass • Housing: PA66 V-0 • Cover: PC |
| Electrical Data | • Standards: IEC 60947-7-1 • Voltage: 500V • Current: 40A • Icw: 4.5kA • Ipk: 22kA |
| Wiring Data | Input (A/B/C): • Connection Points: 2 per phase • Torque: 2-3N·m • Wire Range: – Rigid: 6-16mm² – Flexible: 4-10mm² Output (A/B/C): |
| Packaging | • 1PC per inner box • 72PCS per master carton |
Key Features:
-
High-density 3-phase distribution (2 inputs/15 outputs)
-
Dual wire type support (rigid & flexible)
-
Phase-separated connections (A/B/C)
-
Variable torque requirements:
-
2-3N·m for main inputs
-
1.2-1.5N·m for outputs
-
-
Compact footprint (50mm width)
Technical Notes:
• All phases have identical specifications
• Outputs support smaller wire gauges than inputs
• Flame-retardant PA66 V-0 housing
• Bulk packaging for commercial use (72 units)
• Input terminals accept larger conductors (up to 16mm² rigid)
