Schneider Duct Temperature and Humidity Sensors SHD100 006902321
The SHD100 is an active sensor, which measures relative humidity (% RH)
and converts the measurement into an electric current 4 … 20 mA or a voltage level 0 … 10 Vdc. SHD100 is intended for duct installation and is used for
relative humidity measurement within air ducts. The transmitter is delivered as
a complete unit, comprising an aluminium mounting flange with the sensing
element, and an amplifier mounted in a separate housing.
The sensor has negligible hysteresis and is insensitive to dust as well as a
wide range of chemicals. The housing accommodates a 20 mm dualdimension conduit. A conduit gland nut is supplied with the unit.
Models with -T also include temperature measurement through use of a
passive thermistor output suitable for connection to the appropriate controller
system type.
Calibration certificates: See Appendix B
Output Selectable, 0 … 10 Vdc or 4 … 20 mA
Range 0 … 95% RH
Accuracy ±2%
Supply 24 Vac/15 … 36 Vdc
006902381
SHD101-T5
