The SLR320 electronic light transmitter converts a lux measurement into a
0 … 10 Vdc output signal or an electric current signal 4 … 20 mA. It has two
sensitivity ranges to suit different light levels:
• 0 … 400 lux (for controlling outdoor lighting)
• 0 … 20k lux (for controlling sunshade systems)
The transmitter is delivered as a complete unit, comprising the sensing
element, and an amplifier mounted in a housing. The transmitter is intended
for wall mounting indoors. The sensitivity peak is for light at an angle of
incidence of 0° to the perpendicular. The sensor has the same spectrum
sensitivity peak as the human eye.
The SLR320 converts a lux measurement into a current signal 4 … 20 mA or
an electric signal 0 … 10 Vdc; selectable by a link located on the PCB.
