15.6 inch Capacitive Touch Industry Panel PC.
| System Parameter | |
| Model | ITPC-B156-CF2 |
| Processor | Intel Celeron J1900/J6412 |
| 4/5th gen Intel Core i5/i7, (the specific model is subject to shipment) |
|
| 6/8/10/11th gen Intel Core i3/i5/i7, (the specific model is subject to shipment) |
|
| Memory | J1900: 1 DDR3L 1333/1600 Ram slot, Max. 8GB
J6412：1 DDR4 3200 Ram slot, Max. 16GB 4/5th gen i5/i7：support 2 DDR3L 1333/1600 Ram slot, 6/8/10/11th gen i3/i5/i7：support 2 DDR4 Ram slot, |
| BIOS | AMI EFI BIOS |
| Display Chip | Intel Graphics |
| Display port | 1 VGA, 1 HDM, 1 LVDS ; (Support Synchronous/Asynchronous Dual Display) |
| Storage | 1*MSATA/M.2 slot (According To The Selected Motherboard) |
| Expansion | 1*MINI PCIE/M.2 slot，(support WIFI/4G , J6412 motherboard doesn’t support 4G ) |
| I/O | 1 power switch, 1 DC, 1 HDM, 1 VGA , 2 USB 3.0, 2 USB 2.0, |
| 2 Gigabit Ethernet, 1 Mic, 1 Line Out, 2 COM (one of Support RS232/485) |
|
| LCD | Size：15.6 inch TFT-LCD； |
| Ratio：16 : 9； | |
| Resolution：1920 * 1080； | |
| Brightness：250 cd/m2； | |
| Full plane front panel, IP65 protection level | |
| Touch Screen | Multi point capacitive touch screen, with a lifespan of over 50 million times; Adopting full lamination technology for lamination with LCD screen |
| Speaker | Two 8-ohm 2-watt speaker(customize the wide voltage, the number of speakers is 1) |
| Power Supply | DC 12V (Optional 9-36V) |
| Certificates | CE、 CCC、 FCC Class A、 ROHS |
| Application | Industrial Automation，Medical， Logistics Transportation, Warehousing, Machine Vision, etc. |
| Structure Parameter | |
| Color | Gray |
| Material | Aluminum alloy chassis |
| Dimension | 384 * 234 * 54 mm |
| Weight | 2.5kg |
| Environmental Parameter | |
| Work Temp | 0℃ ~ +50℃, surface air flow; Humidity: 5% ~ 95% non-condensing state |
| Work Humidity | 5% ～ 95% Non-condensing |
