4U Firewall Rack Mount Chassis Network Cloud Server with Intel Core I3 I5 I7 Processor Dual Lan Industrial PC
|
Specification |
|||
|
Model |
ZPC-410(B75) |
||
|
Case Color |
White(color can be customized) |
||
|
Material |
Advanced flowerless galvanized sheet 19” 4U Server Case |
||
|
CPU |
Intel Core i3 3210 dual core 3.2Ghz Intel Core i5 3450 quad core 3.1GHz Intel Core i7 3770 quad core 3.4Ghz |
||
|
Chipset |
Adopt Intel B75 chipset |
||
|
BIOS |
AMI UEFI BIOS |
||
|
RAM |
Support 2*DDR3 DIMM ram slot, support max 16G |
||
|
Storage |
Support 1*2.5”/3.5” SSD/HDD (2*2.5” SSD/HDD optional) |
||
|
Display Chip |
Integrated Intel HD Graphics Card 2500/4000 |
||
|
Display Interface |
1*VGA, 1*DVI-D |
||
|
I/O |
4*USB3.0, 2*USB2.0 |
||
|
1*VGA, 1*DVI-D |
|||
|
2*1000M Lan |
|||
|
6*COM (COM2 support RS232/422/485 COM) |
|||
|
2*PS/2 |
|||
|
2*Audio |
|||
|
1*Power Switch |
|||
|
Network Card |
2*RTL 8111E 1000M Lan |
||
|
Expansion |
Support 1*PCIE X16 Slot |
||
|
Support 1*PCIE X4 Slot |
|||
|
Support 2*PCI Slot, Built-in 1*USB2.0 |
|||
|
Optional interface: CPIO, LPT, 4*USB2.0 (standard version without this port) |
|||
|
Watch Dog Timer |
Support |
||
|
Power Supply |
AC 180V~230V (50~60Hz), 250W rated power; (DC 18~36V, 200W rated power optional) |
||
|
Operating System |
Support Windows XP/7/8/10, Linux OS |
||
|
Working Temperature |
-10°C – 60°C |
||
|
Working Humidity |
5% – 95% relative humidity, Non-condensing |
||
|
Size |
263*155*330 mm (L*W*H); |
||
|
Latest Price List |
Click here, contact us to get the latest price list and more info |
||
|
Application |
Applied in Network server, KIOSK, Advertising Machine, Self-service Terminal, Electronic Whiteboard, ATM, POS/Retail, Networking, Automation, Surveillance Parking Pay Station, Channel System, Medical electronic etc . |
||
