AC surge protective device LY1-C40M/2(S)PLUGGABLE SINGLE-POLE SPD,
Our mini size 40kA 2P GDT AC surge protective device is engineered for applications that require compact construction and high surge discharge capability. As a professional manufacturer, factory, and OEM/ODM supplier, we provide wholesale and bulk buy / in bulk solutions to global clients in the AC power protection industry. This model uses a high-performance gas discharge tube (GDT) filled with non-active Ne (neon) gas, delivering extremely fast response time and stable performance under lightning or switching surges. Unlike MOV-only structures, GDT protection offers higher insulation resistance and lower leakage current, making it ideal for sensitive equipment, small control panels, and space-limited power distribution boxes.
The enclosure is made of PVC/PA66/PBT, offering excellent electrical insulation, heat resistance, and mechanical durability. It is designed for 35mm DIN-rail installation, making the device suitable for modular power systems, automation cabinets, and compact distribution units. The 40kA surge capacity ensures reliable protection for residential, commercial, and industrial AC systems. Each unit is built strictly according to IEC 61643-11:2011 / EN 61643-11:2022, and is certified by CE & TUV, ensuring safe operation and long-term reliability.
This 2-pole design fits L+N configurations in single-phase circuits and can be used in power supply, equipment cabinets, solar inverter AC output, UPS systems, and similar applications. Ideal for wholesalers and distributors looking for high-quality, factory-direct protection devices with competitive pricing and strong OEM customization capability. Our production line also supports logo printing, housing color customization, and OEM circuit parameters to match customer requirements. With proven performance and compact dimensions, this mini size 40kA GDT SPD is a smart choice for those seeking a reliable and space-saving surge protection solution.
| ■ Technical Data | |||||||
| IEC Electrical | 75 | 150 | 275 | 320 | 385 | 440 | |
| Nominal AC Voltage (50/60Hz) | Uo/ Un | 60 V | 120 V | 230 V | 230 V | 230 V | 400 V |
| Maximum Continuous Operating Voltage (AC) | Uc | 75 V | 150 V | 275V | 320 V | 385 V | 440 V |
| Nominal Discharge Current (8/20 μs) | In | 20 kA | 20 kA | 20 kA | 20 kA | 20 kA | 20 kA |
| Maximum Discharge Current (8/20 μs) | Imax | 40 kA | 40 kA | 40 kA | 40 kA | 40 kA | 40 kA |
| Impulse Current (10/350μs) | Iimp | 7kA | |||||
| Voltage Protection Level | Up | 0.4 kV | 1 kV | 1.5 kV | 1.6 kV | 1.8 kV | 2 kV |
| Response Time | tA | < 25 ns | |||||
| Back-Up Fuse (max) | 63 A gL / gG | ||||||
| Short-Circuit Current Rating (AC) | ISCCR | 25kA | |||||
| TOV Withstand 5s | UT | 90V | 180V | 335V | 335V | 335V | 580V |
| TOV 120min | UT | 115V | 230V | 440V | 440V | 440V | 765V |
| mode | Withstand | Withstand | Safe Fail | Safe Fail | Safe Fail | Safe Fail | |
| Mechanical & Environmental | |||||||
| Operating Temperature Range | Ta | -40ºF to +158ºF [-40ºC to +70ºC] | |||||
| Permissible Operating Humidity | RH | 5%…95% | |||||
| Atmospheric pressure and altitude | 80k Pa … 106k Pa / -500 m…… 2000 m | ||||||
| Terminal Screw Torque | Mmax | 39.9 Ibf·in[4.5 Nm] | |||||
| Conductor Cross Section (max) | 2 AWG (Solid, Stranded) / 4 AWG (Flexible) | ||||||
| 35 mm² (Solid, Stranded) / 25 mm²(Flexible) | |||||||
| Mounting | 35 mm DIN Rail, EN 60715 | ||||||
| Degree of Protection | IP 20 (built-in) | ||||||
| Housing Material | Thermoplastic: Extinguishing Degree UL 94 V-0 | ||||||
| Thermal Protection | Yes | ||||||
| Operating State / Fault Indication | Green ok / Red defect | ||||||
| Remote Contacts (RC) RC Switching Capacity RC Conductor Cross Section (max) |
Optional AC: 250V / 0.5 A; DC: 250V / 0.1 A;125V / 0.2 A;75V / 0.5 A 16 AWG (Solid) / 1.5 mm²(Solid) |
||||||
