Danfoss 131L9867 Frequency Converter FC-101P5K5T4E20H4XXCXXXSXXXXAXBXCXXXXDX
VLT® HVAC Drive FC- 101
(P5K5) 5.5 KW / 7.5 HP, Three phase
380 – 480 VAC, (E20) IP20 / Chassis
RFI class A1 (C2)
No brake chopper
No Loc. Cont. Panel
Coated PCB, No Mains Option
No A Option, No B Option
No C1 option, No D option
Frame: H3
Other options according to Model Code
Model code:FC-101P5K5T4E20H4XXCXXXSXXXXAXBXCXXXXDX
These drives offer a wide range of powerful standard and optional features with low overall cost of ownership, ideal for OEMs.
VLT® HVAC Basic Drive FC 101 is the natural choice for heating, ventilation, air conditioning, and simple compressor applications. It is optionally available with a 2-line alphanumeric display.
Product details
| Gross weight | 5.1 Kilogram | ||
| Net weight | 4.3 Kilogram | ||
| Volume | 13.23 Liter | ||
| EAN | 5702427807570 |
| Product View (Switch) | GLBL | Global (Standard) | |
| Product Group | FC- | VLT® HVAC Drive FC- | |
| Series | 101 | 101 | |
| Power Rating | P5K5 | (P5K5) 5.5 KW / 7.5 HP | |
| Phase | T | Three phase | |
| Mains Voltage | 4 | 380 – 480 VAC | |
| Enclosure | E20 | (E20) IP20 / Chassis | |
| RFI Filter | H4 | RFI class A1 (C2) | |
| Brake – Safe Stop | X | No brake chopper | |
| LCP | X | No Loc. Cont. Panel | |
| Coating PCB | C | Coated PCB | |
| Mains Option | X | No Mains Option | |
| Adaptation A | X | Standard Cable Entries | |
| Adaptation B | X | No adaptation | |
| Software Release | SXXX | Latest release std. SW. | |
| Software Language Pack | X | Standard Language Pack | |
| A Option | AX | No A Option | |
| B Option | BX | No B Option | |
| C0 Option MCO | CX | No C0 option | |
| C1 Option | X | No C1 option | |
| C Option Software | XX | No software option | |
| D Option | DX | No D option | |
| Frame Size | H3 | H3 | |
| Product Catalog | NO_VIEW | NO VIEW | |
| Typecode Part 1 | FC-101P5K5T4E20H4XXC | ||
| Typecode Part 2 | XXXSXXXXAXBXCXXXXDX | ||
| Product View (Default) | Global (Standard) | ||
| Calculated Net Weight [kg] | 4.8 | ||
| Calculated Gross Weight [kg] | 5.1 | ||
| ECCN EU | Y901 | Y901 | |
| ECCN US | 3A999.a | 3A999.a | |
| Vendor | ERR01 | Cannot Determine Vendor | |
| Recommended Factory | ERR01 | Cannot Determine Vendor | |
| Modelcode01 | FC-101P5K5T4E20H4XXC | ||
| Modelcode02 | XXXSXXXXAXBXCXXXXDX | ||
| Recommended Plant | ERR01 | ERR01 |
