Danfoss 132F0026 Frequency Converter VLT® Micro Drive FC-51 FC-051P4K0T4E20H3BXCXXXSXXX
Frequency Converter
FC-051P4K0T4E20H3BXCXXXSXXX
NB: Last time buy June 30, 2026
VLT® Micro Drive FC-51
(P4K0) 4.0 KW / 5.0 HP, Three phase
380 – 480 VAC, (E20) IP20 / Chassis
(H3) RFI Class A1/B (C1)
Brake chopper
No Loc. Cont. Panel
Coated PCB, No Mains Option
M3-FRAME
Other options according to Model code
Model code:FC-051P4K0T4E20H3BXCXXXSXXX
The VLT® Micro Drive is a general-purpose drive that can control AC motors up to 22.0 kW. It is a small drive with maximum strength and reliability. The VLT® Micro Drive is manufactured with respect for the environment, and it complies with the RoHS Directive.
Product details
| Gross weight | 3.236 Kilogram | ||
| Net weight | 2.716 Kilogram | ||
| Volume | 4.612 Liter | ||
| EAN | 5702427357594 |
| Product View (Switch) | GLBL | Global (Standard) | |
| Product Group | FC- | VLT® Micro Drive FC- | |
| Micro Drive Series | 051 | 51 | |
| Power Rating | P4K0 | (P4K0) 4.0 KW / 5.0 HP | |
| Phase | T | Three phase | |
| Mains Voltage | 4 | 380 – 480 VAC | |
| Enclosure | E20 | (E20) IP20 / Chassis | |
| RFI Filter | H3 | (H3) RFI Class A1/B (C1) | |
| Brake – Safe Stop | B | Brake chopper | |
| LCP | X | No Loc. Cont. Panel | |
| Coating PCB | C | Coated PCB | |
| Mains Option | X | No Mains Option | |
| Adaptation A | X | Standard Cable Entries | |
| Adaptation B | X | No adaptation | |
| Software Release | SXXX | Latest release std. SW. | |
| Frame Size | M3 | M3-FRAME | |
| Typecode Part 1 | FC-051P4K0T4E20H3BXCXXXSXXX | ||
| Modelcode01 | FC-051P4K0T4E20H3BXCXXXSXXX | ||
| Product Catalog | GLBL | Global (Standard) | |
| Calculated Gross Weight [kg] | 3.3 | ||
| Calculated Net Weight [kg] | 3 | ||
| ECCN EU | Y901 | Y901 | |
| ECCN US | 3A999.a | 3A999.a | |
| Plant from Orderline | B902 | B902 | |
| Vendor | ERR01 | Cannot Determine Vendor | |
| Recommended Factory | ERR01 | Cannot Determine Vendor | |
| DrivePro category | EXCH | Exchange Unit |
