FJ-E50x5 Terminal Block Specifications
| Category | Specifications |
|---|---|
| Certifications | CB/CE/LUKCA/RoHS |
| Item Code | FJ-E50x5 |
| Color Options | Gray, Blue, Green |
| Dimensions | 50.3×87.2×43.5mm |
| Weight | 161.4g |
| Screw Type | Hexagon H5 |
| Housing Material | PA66 V0 (Flame Retardant) |
| Conductor Material | Tin-Coated Aluminum |
| Standards | IEC/EN 60947-7-1, IEC/EN 61238-1 |
| Electrical Ratings | • Current: Cu 160A / Al 145A • Voltage: 1000VAC 1500VDC |
| Torque Specifications | • 4Nm (2.5-4mm²) • 12Nm (6-50mm²) |
| Wire Compatibility | • 5 Poles • Copper: 2.5-50mm² • Aluminum: 6-50mm² |
| Packaging | • 3PCS per inner box • 72PCS per master carton |
Key Features:
-
High-current 5-pole terminal block (160A copper/145A aluminum)
-
Available in three color variants (gray/blue/green)
-
Heavy-duty H5 hexagon screw terminals
-
Dual torque settings for precision wiring:
-
4Nm for 2.5-4mm² wires
-
12Nm for 6-50mm² wires
-
-
Expanded wire range (copper 2.5-50mm² / aluminum 6-50mm²)
-
Industrial-grade flame-retardant housing (PA66 V0)
