![Danfoss 017B0002 Pressure switch, BCP1 Regulation range [bar] Pe: 0.1 - 1.1, Differential [bar]: 0.15 - 0.6, Reset function: Auto, Pressure connection type: G, Pressure connection size: 1/2, Enclosure rating IP: IP65, Max. Working Pressure [bar]: 6](https://hsgroupexport.com/wp-content/uploads/2025/08/ID106642041568-0101_preview-300x300.jpg)
15 Inch Touch Screen J1900 Industrial Panel PC,
Specifications
|
Model
|
ITPC-B150-CP2
|
|
Color
|
Grey
|
|
Material
|
Aluminum alloy chassis+ steel plate
|
|
Size
|
15 inch TFT-LCD
|
|
Ratio
|
4 : 3
|
|
Resolution
|
1024*768
|
|
50Brightness
|
350 cd/m2
|
|
Touch Screen
|
Multi point capacitive touch screen,
with a lifespan of over 50 million times |
|
Processor
|
Intel Celeron J1900
|
|
4th/5th gen Intel Core i5/i7 (the specific model is subject to shipment)
|
|
|
Chipset
|
Intel Graphics
|
|
RAM
|
J1900: 1 DDR3L 1333/1600 Ram slot,
Max. 8GB |
|
4th/5th Gen i5/i7: 2 DDR3L 1333/1600 Ram slot,
Max. 16GB |
|
|
Storage
|
Support 1x M.2 slot
|
|
Display Chip
|
Intel Graphics
|
|
Expansion Slot
|
6th Gen processor,
Support 1x Mini PCIE slot (WIFI/4G Optional） |
|
8/10/11th Gen processor,
Support 2xM.2 slot (support WiFi+4G) |
|
|
I/O
|
1 Power Switch, 1 DC ,
1 HD-M-I, 1 VGA, 2 USB 3.0, 2 USB 2.0, |
|
2 Gigabit Ethernet ports,
1 Mic, 1 Line Out, 2 COM (COM1,2 RS232/485) |
|
|
Speaker
|
Two 8-ohm 2-watt speaker(customize the wide voltage,
the number of speakers is 1)
|
|
Input Voltage
|
DC 12V (Optional 9-36V)
|
|
Work Temp
|
0℃ ~ +50℃, surface air flow
|
|
Humidity
|
5% ~ 95% non-condensing state
|
|
Input Voltage
|
DC 12V (Optional 9-36V)
|
|
Dimension
|
346*271*48 mm
|
|
Weight
|
2.7 kg
|
