FESTO VEAB-B-26-D13-F-LK-1R1 Proportional-pressure regulator

FESTO VEAB-B-26-D13-F-LK-1R1 Proportional-pressure regulator

• Valve function3-way proportional-pressure regulator, closed
• Flow directionNon-reversible
• Type of pilotingDirect
• Type of resetMechanical spring
• Type of actuationElectric
• Mounting positionoptional
• Grid dimension18 mm
• Sealing principleSoft
• Total leakage1 l/h
• Symbol00995607
• Ambient temperature0 °C … 50 °C
• Media temperature5 °C … 50 °C
• Storage temperature-20 °C … 70 °C
• Relative air humidity5 – 85 %
• Dimensions (W x L x H)18 x 67 x 66 mm
• Pneumatic connection, port 1Flange
• Pneumatic connection, port 2Flange
• Pneumatic connection, port 3Flange
• Material sealsEPDM HNBR
• Type of mountingEither: With through-hole With accessories
• Inlet pressure 10 MPa … 0.2 MPa
• Inlet pressure 10 bar … 2 bar
• Inlet pressure 10 psi … 29 psi
• Burst pressure18 bar
• Output pressure 2-0.1 MPa … 0.1 MPa
• Output pressure 2-1 bar … 1 bar
• Output pressure 2-14.5 psi … 14.5 psi
• Input pressure 3-0.1 MPa
• Input pressure 3-1 bar
• Input pressure 3-14.5 psi
• Standard nominal flow rate (standardised to DIN 1343)≥17 l/min
• Standard nominal flow rate 2-3≥13 l/min
• Linearity0.25 %FS
• Reproducibility0.2 %FS
• Hysteresis0.25 %FS
• Temperature cooefficient0.05 %/K
• Total accuracy0.5% FS
• Product weight70 g
• Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4] Inert gases
• Note on operating and pilot mediumLubricated operation not possible
• Nominal altitude of use< 3000 m NHN
• Instructions on useThe device has been developed, designed and built exclusively for industrial and commercial use. The device has not been authorised for private use.
• Degree of protectionIP65
• ApprovalRCM trademark
• KC markKC-EMV
• CE mark (see declaration of conformity)To EU EMC Directive In accordance with EU RoHS Directive
• UKCA marking (see declaration of conformity)To UK instructions for EMC To UK RoHS instructions
• Note on materialsRoHS-compliant
• LABS (PWIS) conformityVDMA24364 zone III
• Corrosion resistance class CRC2 – Moderate corrosion stress
• Operational voltage range DC18 V … 30 V
• Nominal operating voltage DC24 V
• Max. current consumption0.083 A
• Residual ripple10 %
• Setpoint value inputIO-Link
• Max. electrical power consumption1.5 W
• Reverse polarity protectionFor all electrical connections
• Short circuit current ratingFor all electrical connections
• Safety instructions
• Display typeLED
• Electrical connection4-pin M8x1 Plugs To EN 60947-5-2
• Max. cable length20 m
• Material housingPA-reinforced
• Vibration resistanceTransport application test with severity level 2 to FN 942017-4 and EN 60068-2-6
• Shock resistanceShock test with severity level 2 to FN 942017-5 and EN 60068-2-27
• IO-Link, Number of ports1
• IO-Link, Protocol versionDevice V 1.1
• IO-Link, Device ID0x03A7
• IO-Link, communication modeCOM3 (230.4 kBaud)
• IO-Link, port typeClass A
• IO-Link, connection technologyDevice 3-pin
• IO-Link, Port classDevice A
• IO-Link, Min. cycle time0.5 ms
• IO-Link, Process data length OUT2 bytes
• IO-Link, Process data length IN2 bytes
