FJ-E35/5 Terminal Block Specifications
| Category | Specifications |
|---|---|
| Certifications | CB/CE/UKCA/RoHS |
| Item Code | FJ-E35/5 |
| Color Options | Gray, Blue, Green |
| Dimensions | 80×45.2×40.2mm |
| Weight | 117.2g |
| Screw Type | Hexagon H4 |
| Housing Material | PA66 V0 (Flame Retardant) |
| Conductor Material | Tin-Coated Aluminum |
| Standards | IEC/EN 60947-7-1, IEC/EN 61238-1 |
| Electrical Ratings | • Current: Cu 135A / Al 120A • Voltage: 1000VAC 1500VDC |
| Torque Specifications | • 3Nm (2.5-16mm²) • 6Nm (25-35mm²) |
| Wire Compatibility | • Metric Wire: 5 Poles • Copper: 2.5-35mm² • Aluminum: 2.5-35mm² |
| Packaging | • 3PCS per inner box • 99PCS total |
Key Features:
-
Multi-certified (CB/CE/UKCA/RoHS compliant)
-
High-current capacity (135A copper/120A aluminum)
-
Wide voltage rating (1000VAC/1500VDC)
-
Versatile wire compatibility (2.5-35mm² for both Cu/Al)
-
Flame-retardant PA66 housing (V0 rating)
-
Industrial-grade hexagon screw terminals (H4 type)
