MDR-10-5 AC to DC DIN-Rail Power Supply 5V 2 Amp 10W,
10W single output industrial DIN rail power supply 5 Volts 2 Amps features,
universal AC input/full range protections: short circuit/overload/over voltage,
cooling by free air convection can installed on DIN rail ts-35/7.5 or 15 NEC,
Class 2/LPS compliant LED indicator for power on no load power consumption,
100 percent full load burn-in Test 3 years warranty built in DC OK active signal detaile,
specifications: primary output voltage (VDC): 5 output current (a): 2 maximum output,
power (W): 10 family: mdr-10 input voltage (VAC): 85 to 264 input frequency: 47 to 63,
maximum input current (a): .33 output connector Type: screw terminal efficiency ( percent ),
77 operating temperature-min (CEL): -20 operating temperature-max (CEL): 70 Length (inch),
0.89 width (inch): 3.54 height (inch): 3.94 agency approvals: UL/cul/TUV/CB/CE color: white style: DIN.
Product details
- Is Discontinued By Manufacturer : No
- Product Dimensions : 0.89 x 3.54 x 3.94 inches; 5.29 ounces
- Item model number : MDR-10-5
- Date First Available : October 10, 2013
- Manufacturer : MEAN WELL
- ASIN : B005T6NAG6
- Best Sellers Rank: #586 in Computer Uninterruptible Power Supply Units
