Shop for Schneider STD Series temperature sensor STD500-150 duct 150 mm Continuum compatible 5123074010

Schneider STD Series temperature sensor STD500-150 duct 150 mm Continuum compatible 5123074010

STD500 temperature sensors are intended for air duct mounting. The STD
housing is equipped with a Ø 20 mm (0.79 in.) cut-out for the cable, a 20 mm
(0.79 in.) conduit gland nut and a mounting flange.
Accuracy: See Appendix A, table C
Calibration certificates: See Appendix B
Thermistor table: See Appendix C, table A

5123076010 STD500-200
5123078010 STD500-250
5123080010 STD500-300
5123082010 STD500-400

Specifications

Main
Range of product	STD500
Product or component type	Sensor
Type of measurement	Temperature
Device application	Duct
IP degree of protection	IP65
location	Plant room
Mounting support	Duct
Depth	44 mm
Height	84 mm
Net weight	0.12 kg
Width	65 mm
Output type	Resistive output
Product compatibility	Continuum
Standards	EN 50082-2 EN 50081-1
Colour	Black and green
Sensor type	10 kOhm NTC temperature
Targeted region	Asia Pacific. Europe

Complementary
Material	Aluminium: mounting flange PA (polyamide): connection box Stainless steel: immersion tube
Time constant	52000 ms 3 l/min 72000 ms 1.5 l/min
Connections – terminals	Wire (AWG 24…AWG 18)
Length	150 mm for side sensor
Measurement accuracy	0…25 °C +/- 0.2 °C

Environment
Temperature probe type	NTC 10000 Ohm at 25 °C
Product certifications	CE

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	28.600 cm
Package 1 Width	9.600 cm
Package 1 Length	7.000 cm
Package 1 Weight	200.000 g
Unit Type of Package 2	BB1
Number of Units in Package 2	40
Package 2 Height	32.000 cm
Package 2 Width	56.000 cm
Package 2 Length	28.000 cm
Package 2 Weight	8.780 g
