MITSUBISHI ELECTRIC GT25H Handy Portable Operator Panels GT2506HS-VTBD,
Key Functions
Ability to Read Documents
VNC Remote Access
FTP Client
Data Logging
Multi Channel (Simultaneous Ethernet + Serial communication)
FA Transparent
Operator protection
Ability to Backup / Restore MELSEC Controllers
GT25 handy
Art. No
Code
Physical properties
6.5”, 5.7” LCD TFT Display
Led Backlight
Analog Touch Panel
65k Color / Monochrome
6-Piece Keypad
IP65F
CE,UL,cUL Certified
Description
331429
Interfaces
GT2506H: RS-232 ; RS-422/485, 2x USB
(1 x Host, 1x Device),
Ethernet; SD Card, 2 communication channels
Optional: CC-Link
GT2505H: RS-232, RS-422, 2x USB
(1 x Host, 1x Device)
Ethernet: SD Card, 1 communication channel
| Series | GOT2000 SERIES |
|---|---|
| Type | GT25 HANDY GOT |
| Display | TFT |
| Display Colour | 65536 |
| Display Size (Inch) | 6,5 |
| Resolution (Pixels) | 640X480 |
| Power Supply (V) | 24 |
| Current Type | DC |
| Protection Class | IP65F |
| Internal Memory Capacity (MB) | 32 |
| Memory Card Slot | SD |
| USB | 2 |
| Ethernet Port | 1 |
| RS-232 | 1 |
| RS-422/485 | 1 |
| Network Options | MODBUS, CCLINK, ETHERNET |
Conformity
| CE | COMPLIANT |
|---|---|
| UL/cUL | COMPLIANT |
| EAC | NON-COMPLIANT |
| Shipping Approvals | NON-COMPLIANT |
| UKCA | COMPLIANT |
Product Dimensions & Weight
| Width (mm) | 201 |
|---|---|
| Height (mm) | 230 |
| Depth (mm) | 118 |
| Weight (kg) | 1,2 |
Product Packaging
| Cardboard (g) | 674 |
|---|---|
| Other paper (g) | 0 |
| Aluminum (g) | 0 |
| Steel (g) | 0 |
| Styrofoam (g) | 0 |
| Other plastic (g) | 10 |
| Wood (g) | 0 |
| Glass (g) | 0 |
| Others (g) | 0 |
GT2505HS-VTBD
