12.1-inch Fanless Industrial Panel Pc features a TFT-LCD display with a 4:3 aspect ratio, 1024×768 resolution,
and high brightness (500 cd/m²).
It includes a durable multi-point capacitive touchscreen rated for over 50 million operations,
seamlessly fitted with the LCD.
The device is equipped with 1x 8Ω2W speaker (customizable for wide voltage input: DC 9–36V),
and supports a DC 12V power supply (9–36V wide voltage optional).
Designed for harsh environments, it operates in temperatures from 0°C to +50°C and humidity levels of 5%–95% (non-condensing).
With compact dimensions (298 × 237 × 48 mm) and a weight of 2.4 kg, it is ideal for industrial automation, medical, logistics,
transportation, warehousing, and e-education applications.
| Model | ITPC-B121-CP2 |
| Processor | Intel Celeron J1900【 Quad Core,1.99GHz 】 |
| 4/5th Gen Intel Core i5/i7(The specific model is subject to shipment) | |
| Chipset | Intel CPU Integrated Chip |
| Memory | Support 1*DDR3L 1333/1600, MAX: 8GB ; 4/5th Gen i5/i7：support 2*DDR3L 1333/1600 memory slot,Max. 16GB |
| Screen size | 12.1Inch TFT-LCD |
| Screen Ratio | 4：3 |
| Resolution | 1024 * 768 |
| Brightness | 500 cd/m2 |
| Touch Screen | Multi-point capacitive touch screen, life can reach more than 50 million times; Fit with LCD screen; |
