Fanless Design Multi-Lan Firewall mini pc,
with nboard Intel quad core 8th Core i5/i7,
and 2*DDR4 RAM Slot Max Support 32G.
| System Parameter | |
| Model | N18 Firewall Mini PC |
| Processor | Onboard Intel Celeron 3867U（Dual core, dual threads，1.8G，2MB Cache）； |
| Onboard Intel Celeron i5 8250U（Quad core， 8 threads，1.6GHz，Max turbo 3.4GHz，Cache 6MB） |
|
| Onboard Intel Core i7 8550U（Quad core ， 8 threads，1.8GHz，Max turbo 4.0GHz，Cache 8MB） |
|
| Chipset | Integrated Intel UHD Graphics 620 |
| Memory | Support 2*DDR4 2133/2400 SODIMM RAM Slot， Max. Support 32GB |
| BIOS | AMI UEFI BIOS |
| Display Port | 1*HDMI，（No sound output） |
| Storage | Support 1*MSATA Slot，1*2.5″HDD |
| Expansion | Support 1* Half height MINI PCIE slot（WIFI/BT Optional） Support 1* Full height MINI PCIE slot（Suooport MSATA/4G， 1* Nano-SIM slot on the plate） |
| Front I/O | 4*USB3.0，1*Power Switch， 1*RJ45 COM（Support Console）,1* HDM |
| Rear I/O | 6* Intel 1000M Lan, 1*DC |
| Network | 6*Intel i211-AT 10/100/1000M LAN |
| Input Voltage | Support DC 12V Input； |
| Certificates | CE、 CCC、 FCC Class A、 ROHS |
| Other Function | Auto power on when there is electricity、 Timing boot、 Wake on LAN、PXE boot、Watchdog （0～255 level）(Standard version doesn’t set these function) |
| Application | Firewall，Network server， Network security，Router etc. |
| Structure Parameter | |
| Color | Black【Any color can be customized】 |
| Material | High-quality all aluminum， surface anodic oxidation |
| Dimension | 186 * 126.5 * 66 mm |
| Weight | 1.3 kg |
| Environmental Parameter | |
| Work Temp | 0℃ ～ +50℃（Commercial HDD）， -20℃ ～ +50℃（Industrial SSD），Surface air flow |
| Work Humidity | 5% ～ 95% non-condensing |
